Renault Trafic Minibus LWB LL30 Blue dCi 150 Advance 9 Seater

Insurance Group 1:

N

Insurance Group 2:

N

Chassis Engine Number:

N

Vin/Frame No.:

N

Coin Series:

N

Coin Description:

N

Standard manufacturers warranty - Years:

3

Standard manufacturers warranty - Mileage:

100000

Manufacturers Paintwork Guarantee - Years:

3

Man Corrosion Perforation Guarantee - Years:

12

Exhaust System:

CATALYTIC CONVERTER

Front Brakes:

VENTILATED DISCS

Rear Brakes:

DISCS

Hand Brake:

REAR WHEELS

Front Suspension:

MACPHERSON STRUTS

Rear Suspension:

COIL SPRINGS

Steering:

PAS RACK AND PINION

Clutch:

SINGLE DRY PLATE

Any aspect of the vehicles safety cause concern?:

Coin Wheelbase Description Code:

N

Coin Wheelbase Name Code:

N

Coin Gross Vehicle Weight Code:

N

Coin Power Output Code:

N

Special Edition:

Special Order:

Based On ID:

0

Running Cost League Headings:

MEDIUM

This vehicle is classed as a car for VED purposes:

1

Ghost model for valuation purposes:

Service Interval Mileage:

24000

Service Interval Frequency - Months:

24

NCAP Adult Occupant Protection %:

0

NCAP Child Occupant Protection %:

0

NCAP Overall Rating - Effective February 09:

0

NCAP Pedestrian Protection %:

0

NCAP Safety Assist %:

0

Badge Engine CC:

2

Badge Power:

150

Vehicle Homologation Class:

M1

VAT qualifying vehicle - Seek advice from HMRC:

1

Generation Mark:

3

NCAP Overall Rating - LCV:

N

Relative Height:

H1

Relative Length:

L2

Minimum Kerbweight:

2077

Gross Vehicle Weight:

3070

Fuel Tank Capacity (Litres):

80

Max. Towing Weight - Braked:

2500

Max. Towing Weight - Unbraked:

750

Payload:

993

Load Space Volume:

1.8

Boot Capacity Saloons:

Luggage Capacity - 2nd Row Seats Up:

Luggage Capacity (Seats Down):

Luggage Capacity - 3rd Row Seats Up:

Luggage Capacity - 3rd Row Seats Down:

Luggage Capacity - 2nd Row Seats Removed:

Luggage Capacity - 3rd Row Seats Removed:

No. of Seats:

9

Max. Roof Load:

0

Luggage Capacity (Seats Up):

0

Plated Front Axle:

1335

Plated 2nd Axle:

1016

Gross Train Weight:

5570

Length:

5480

Width (excluding mirrors):

1956

Wheelbase:

3498

Width (including mirrors):

2312

Height:

1973

Height (including roof rails):

0

Load Length:

1136

Load Width:

1230

Turning Circle - Kerb to Kerb:

13.8

Front Overhang:

1014

Rear Overhang:

968

Side Load Door Width:

907

Side Load Door Height:

1284

Lower Rear Door Width:

1255

Upper Rear Door Width:

1320

Rear Door Height:

1295

Load Deck Height:

552

Load Space Width Between Wheel Arches:

1230

Turning Circle - Wall to Wall:

14.3

EC:

WLTP - FC (l/100km) - Comb:

7

WLTP - MPG - Comb:

40.4

0 to 62:

13.6

Top Speed:

110

BHP:

150

PS:

1

0 to 60:

Engine Power KW:

110

Engine Power RPM:

3500

Engine Torque LBS.FT:

258

Engine Torque NM:

350

Engine Torque RPM:

1500

Engine Torque MKG:

35.7

Bore:

85

Stroke:

88

CC:

1997

Cylinders:

4

Cylinder Layout:

IN-LINE

Number of Valves:

16

Valve gear:

DOHC

Fuel Type:

DIESEL

Catalytic Convertor:

1

Engine Layout:

FRONT TRANSVERSE

Compression Ratio:

15.1:1

Gears:

6 SPEED

Engine Make:

N

Fuel Delivery:

COMMON RAIL

Cooling System:

WATER

Automatic Transmission:

Manual Transmission:

1

Tyre Size Front:

215/65 R16

Tyre Size Rear:

215/65 R16

Tyre Size Spare:

FULL SIZE

Wheel Type:

16" STEEL

Wheel Style:

SIRAS

Tyre Make:

N

Plated 3rd Axle:

0

Plated 4th Axle:

0

Alloys?:

Space Saver?:

Automatic Clutch:

Standard Emissions:

EURO 6

Noise Level dB(A):

CO:

NOx:

0.068

HC+NOx:

Particles:

HC:

WLTP - CO2 (g/km) - Comb:

182

Emissions Test Cycle:

WLTP

RDE Certification Level:

RDE 2

Remote central locking:

Electronic immobiliser:

Alarm pre - wiring:

Deadlocking:

3 button folding key:

PAS:

Cruise control with speed limiter:

Lane departure warning system:

Intelligent Speed Assist:

Driver attention alert:

Driver drowsiness warning:

Trip computer:

Service indicator:

Tyre pressure monitor:

Eco mode:

7" Colour TFT driver information display:

Rear glazed tailgate heated with wash/wipe:

Reach and rake adjustable steering column:

Parcel shelf:

Closed glovebox:

Load area protective rubber mat:

Kompo cloth upholstery:

Dashboard with geometric grain:

Electric front windows with one touch drivers window:

Dark tinted windows - side and rear:

Automatic headlights:

Full LED headlights with C-shaped DRL:

Spare wheel with anti theft wheel holder:

Front lateral and curtain airbags with passenger airbag deactivation:

3 point height adjustable seatbelts with pretensioners and load limiter:

2 ISOFIX points for 2nd row and outer seats:

Driver and front passenger airbag:

3rd row of 3 passenger seats removeable:

Driver and passenger seatbelt reminder:

Emergency call button:

Rear parking sensor:

80 litre fuel tank:

20L AdBlue tank:

Wide view mirror:

Heated with electric adjustment door mirrors and external temperature sensors:

4 disc brakes:

ABS with EBD (Electronic Brake force Distribution):

ESC (Electronic Stability Control) with Hill Start Assist and Grip Xtend:

Active emergency braking system:

6 speed gearbox with gearshift indicator:

Removeable 2nd row of 3 passenger seats:

Height adjustable drivers seat with armrest and lumbar adjustment:

Interior lighting:

16" Siras steel with large wheel stylers:

16" steel wheel trims:

12V power socket in 2nd row:

Half painted front and rear bumpers, body coloured door rail, rear tail light column and chrome grille:

Additional heating in the passgenger area:
