Kia PV5 Cargo 89kW Essential Standard Range 52kWh H1 Van Auto

Insurance Group 1:

N

Insurance Group 2:

N

Chassis Engine Number:

N

Coin Series:

N

Coin Description:

N

Standard manufacturers warranty - Years:

7

Standard manufacturers warranty - Mileage:

100000

Exhaust System:

N

Front Suspension:

DOUBLE WISHBONE

Rear Suspension:

TORSION BEAM AXLE

Coin Wheelbase Description Code:

N

Coin Wheelbase Name Code:

N

Coin Gross Vehicle Weight Code:

N

Coin Power Output Code:

N

Special Edition:

Special Order:

Based On ID:

0

Running Cost League Headings:

MEDIUM

Service Interval Mileage:

20000

Service Interval Frequency - Months:

24

Timing Belt Interval Mileage:

0

Timing Belt Interval Frequency - Months:

0

NCAP Adult Occupant Protection %:

0

NCAP Child Occupant Protection %:

0

NCAP Overall Rating - Effective February 09:

0

NCAP Pedestrian Protection %:

0

NCAP Safety Assist %:

0

Badge Power:

120

Vehicle Homologation Class:

N1

Alternative Fuel Qualifying:

1

Generation Mark:

1

NCAP Overall Rating - LCV:

5 Star

Relative Height:

H1

Relative Length:

L1

Minimum Kerbweight:

1775

Gross Vehicle Weight:

2650

Fuel Tank Capacity (Litres):

Max. Towing Weight - Braked:

750

Payload:

875

Load Space Volume:

4

Luggage Capacity - 2nd Row Seats Up:

Luggage Capacity (Seats Down):

Luggage Capacity - 3rd Row Seats Up:

Luggage Capacity - 3rd Row Seats Down:

Luggage Capacity - 2nd Row Seats Removed:

Luggage Capacity - 3rd Row Seats Removed:

No. of Seats:

2

Max. Roof Load:

100

Luggage Capacity (Seats Up):

0

Length:

4495

Width (excluding mirrors):

1895

Wheelbase:

2995

Width (including mirrors):

2255

Height:

1899

Load Length:

2055

Load Width:

1565

Load Height:

1520

Turning Circle - Kerb to Kerb:

11

Side Load Door Width:

775

Load Deck Height:

419

Load Space Width Between Wheel Arches:

1330

0 to 62:

16.2

Top Speed:

84

BHP:

120

PS:

0 to 60:

Engine Power KW:

89

Engine Torque LBS.FT:

184

Engine Torque NM:

250

Engine Torque MKG:

25.5

Bore:

Stroke:

CC:

1

Cylinders:

0

Cylinder Layout:

N

Number of Valves:

0

Valve gear:

N

Fuel Type:

ELECTRIC

Catalytic Convertor:

Engine Layout:

N

Compression Ratio:

N

Gears:

1 SPEED

Engine Make:

N

Fuel Delivery:

N

Cooling System:

N

Automatic Transmission:

1

Manual Transmission:

Engine Codes:

N

Tyre Size Front:

215/65 R16

Tyre Size Rear:

215/65 R16

Tyre Size Spare:

TYRE REPAIR KIT

Wheel Type:

16" STEEL

Wheel Style:

N

Tyre Make:

N

Alloys?:

Space Saver?:

CO2:

0

Standard Emissions:

N

Noise Level dB(A):

65

CO:

NOx:

HC+NOx:

Particles:

HC:

Battery Capacity in kWh:

51.5

Battery Charging Scenario 1 - Power Supply - kW:

7

Battery Charging Scenario 1 - Percentage Change:

10-100

Battery Charging Scenario 1 - Charge Time (Mins):

420

Battery Charging Scenario 2 - Power Supply - kW:

11

Battery Charging Scenario 2 - Percentage Change:

10-100

Battery Charging Scenario 2 - Charge Time (Mins):

285

Battery Charging Scenario 3 - Power Supply - kW:

150

Battery Charging Scenario 3 - Percentage Change:

10-80

Battery Charging Scenario 3 - Charge Time (Mins):

30

Battery Charging Scenario 4 - Power Supply - kW:

Battery Charging Scenario 4 - Charge Time (Mins):

0

Battery Leased:

Battery Type:

Lithium-ion

Standard manufacturers Battery warranty - Mileage:

100000

Standard manufacturers Battery warranty - Years:

8

WLTP - EC (kWh/100km) - Comb:

19.4

Coupler/Connector Type:

CCS Type 2

WLTP - Pure Electric Range (km) - Comb:

288

Battery Charging Scenario 4 - Percentage Change:

N

WLTP - EC (miles/kWh) - Comb:

3.2

WLTP - Pure Electric Range (miles) - Comb:

179

Battery Capacity % guaranteed under warranty:

70

Charging Port Location:

Front

Usable Battery Capacity:

48

Maximum Charging Rate - kW:

150

Emissions Test Cycle:

WLTP

RDE Certification Level:

N

PAS:

Reversing camera:

Manual speed limit assist:

Lane following assist 2:

Lane keep assist - Line/Road Edge:

Highway driving assist:

Forward collision avoidance assist 1.5 - City, Pedestrian, Cyclist & Junction Turning:

Single front passenger seat:

Manual height adjustment for front seats:

Driver lumbar support:

Height adjustable headrests:

Voice recognition:

Front and rear parking sensors:

Intelligent speed limit assistance:

Drive mode selector (Eco/Normal/Snow):

Cloth upholstery:

Driver and passenger sunvisors + vanity mirrors:

Console box:

Driver underseat storage tray:

Front passenger underseat storage tray:

Manually adjustable tilt and telescopic steering wheel:

2 Spoke Bio-artifical leather steering wheel:

Fabric headlining:

Driver and passenger footwell under floor storage:

2 speakers:

Remote audio controls:

1x 100W USB-C charging port:

1x Additional USB-C charging port:

Height adjustable front seatbelts:

Curtain airbags:

Emergency stop signal system:

3 point seat belts:

Driver and front passenger airbags:

Side thorax and pelvis airbags in front row:

Driver and passenger seatbelt reminder:

Tyre pressure monitoring system (TPMS):

Alarm and immobiliser:

Visible Vehicle Identification Number (VIN):

Smart Key:

Start/Stop button with smart entry system:

Tyre repair kit:

Automatic air conditioning:

Gloss black door mirrors:

Electrically adjustable and heated door mirrors:

LED Daytime running lights:

LED rear lights:

LED door mirror indicator:

LED headlamps:

Automatic headlight control:

LED rear fog lights:

Anti lock braking system (ABS):

Regenerative braking paddle shifter:

eCall emergency system:

Over the air updates:

12.9" Touchscreen Navigation:

7.5" Driver display screen:

Driver one touch electric windows:

Rain sensing front wipers:

Automatic window defogger system:

Wireless Apple CarPlay and Android Auto:

Bluetooth connection:

11 kW AC charging power:

LED cabin lights:

2X LED cargo light:

16" Steel wheels with full size wheel cover:

3 Piece front and rear bumper:

Plastic composite bulkhead:
