Fiat E-Ducato Large Van 35 L3 205kW 110kWh H2 Van Auto [22kW Ch]

Insurance Group 1:

N

Insurance Group 2:

N

Chassis Engine Number:

N

Vin/Frame No.:

N

Coin Series:

N

Coin Description:

N

Exhaust System:

N

Front Brakes:

VENTILATED DISCS

Rear Brakes:

DISCS

Hand Brake:

REAR

Front Suspension:

MCPHERSON STRUTS

Rear Suspension:

LONGITUDINAL LEAF SPRINGS

Steering:

PAS RACK AND PINION

Clutch:

N

Any aspect of the vehicles safety cause concern?:

Coin Wheelbase Description Code:

N

Coin Wheelbase Name Code:

N

Coin Gross Vehicle Weight Code:

N

Coin Power Output Code:

N

Special Edition:

Special Order:

Based On ID:

0

Running Cost League Headings:

LARGE

This vehicle is classed as a car for VED purposes:

Ghost model for valuation purposes:

Service Interval Mileage:

16000

Service Interval Frequency - Months:

12

Timing Belt Interval Mileage:

0

Timing Belt Interval Frequency - Months:

0

NCAP Adult Occupant Protection %:

0

NCAP Child Occupant Protection %:

0

NCAP Overall Rating - Effective February 09:

0

NCAP Pedestrian Protection %:

0

NCAP Safety Assist %:

78

Badge Engine CC:

0

Badge Power:

279

Vehicle Homologation Class:

N1

Alternative Fuel Qualifying:

1

Generation Mark:

3

NCAP Overall Rating - LCV:

Gold

Relative Height:

H2

Relative Length:

L3

Minimum Kerbweight:

2790

Gross Vehicle Weight:

3500

Fuel Tank Capacity (Litres):

Max. Towing Weight - Braked:

2400

Max. Towing Weight - Unbraked:

750

Payload:

710

Load Space Volume:

13

Luggage Capacity - 2nd Row Seats Up:

Luggage Capacity (Seats Down):

Luggage Capacity - 3rd Row Seats Up:

Luggage Capacity - 3rd Row Seats Down:

Luggage Capacity - 2nd Row Seats Removed:

Luggage Capacity - 3rd Row Seats Removed:

No. of Seats:

3

Max. Roof Load:

100

Luggage Capacity (Seats Up):

0

Plated Front Axle:

2100

Plated 2nd Axle:

2400

Gross Train Weight:

5500

Length:

5998

Width (excluding mirrors):

2050

Wheelbase:

4035

Height:

2522

Load Length:

3705

Load Width:

1870

Load Height:

1932

Front Overhang:

948

Rear Overhang:

1015

Side Load Door Width:

1250

Side Load Door Height:

1755

Lower Rear Door Width:

1562

Rear Door Height:

1790

Load Space Width Between Wheel Arches:

1422

EC:

EC Urban:

EC Extra Urban:

EC Combined:

0 to 62:

10

Top Speed:

81

BHP:

279

PS:

1

0 to 60:

Engine Power KW:

205

Engine Torque LBS.FT:

302

Engine Torque NM:

410

Engine Torque MKG:

41.8

Bore:

Stroke:

CC:

1

Cylinders:

0

Cylinder Layout:

N

Number of Valves:

0

Valve gear:

N

Fuel Type:

ELECTRIC

Catalytic Convertor:

Engine Layout:

N

Compression Ratio:

N

Gears:

1 SPEED

Engine Make:

N

Fuel Delivery:

N

Cooling System:

N

Automatic Transmission:

1

Manual Transmission:

Engine Codes:

N

Tyre Size Front:

215/70 R15

Tyre Size Rear:

215/70 R15

Tyre Size Spare:

TYRE REPAIR KIT

Wheel Type:

15" STEEL

Wheel Style:

N

Tyre Make:

N

Plated 3rd Axle:

0

Plated 4th Axle:

0

Alloys?:

Space Saver?:

Automatic Clutch:

CO2:

0

Standard Emissions:

N

Noise Level dB(A):

CO:

NOx:

HC+NOx:

Particles:

HC:

Battery Capacity in kWh:

110.6

Battery Charging Scenario 1 - Power Supply - kW:

7.4

Battery Charging Scenario 1 - Percentage Change:

0-100

Battery Charging Scenario 1 - Charge Time (Mins):

1000

Battery Charging Scenario 2 - Power Supply - kW:

22

Battery Charging Scenario 2 - Percentage Change:

0-100

Battery Charging Scenario 2 - Charge Time (Mins):

365

Battery Charging Scenario 3 - Power Supply - kW:

150

Battery Charging Scenario 3 - Percentage Change:

5-80

Battery Charging Scenario 3 - Charge Time (Mins):

55

Battery Charging Scenario 4 - Power Supply - kW:

Battery Charging Scenario 4 - Charge Time (Mins):

0

Battery Leased:

Battery Type:

Lithium-ion

Standard manufacturers Battery warranty - Mileage:

100000

Standard manufacturers Battery warranty - Years:

8

WLTP - EC (kWh/100km) - Comb:

29.4

WLTP - EC (kWh/100km) - City:

20.7

Coupler/Connector Type:

CCS Type 2

WLTP - Pure Electric Range (km) - City:

537

WLTP - Pure Electric Range (km) - Comb:

378

Battery Charging Scenario 4 - Percentage Change:

N

WLTP - EC (miles/kWh) - City:

3

WLTP - EC (miles/kWh) - Comb:

2.1

WLTP - Pure Electric Range (miles) - City:

334

WLTP - Pure Electric Range (miles) - Comb:

235

Battery Capacity % guaranteed under warranty:

70

Charging Port Location:

Left Side Front

Usable Battery Capacity:

97.8

Maximum Charging Rate - kW:

150

Emissions Test Cycle:

WLTP

RDE Certification Level:

N

Driver's airbag:

Dual passenger airbag:

Electric front windows:

Service indicator:

TPMS (Tyre pressure monitoring system):

Full 7" digital instrument cluster:

Global telematics box module:

Side protection rubbing strips:

Aerodynamic kit - Central spoiler, air guides, active grille shutter:

4 sensor ABS + EBD:

Electric parking brake:

Electronic Stability Control (ESC):

Automatic air conditioning:

Traffic sign recognition:

Electric power steering:

Intelligent Speed Assist:

Driver drowsiness detection:

Advanced emergency braking system - Pedestrian and cyclist:

Nearside sliding side loading door:

Twin lens door mirrors with electrically adjustable and heated upper mirror:

Two cup holders and mobile phone storage in centre of lower dashboard:

Crepe premium cloth upholstery:

Perimetric alarm and deadlocks:

Remote control central deadlocking with immobiliser:

Fix and go kit:

Lane support system:

Connected services:

Steel wheel centre caps:

Siri and Google assistant without CP/AA connection:

Steering wheel command interface:

Cargo lashing hooks in rear:

6 way driver's seat with lumbar adjustment and armrest:
