Vauxhall Astra Estate 1.2 Turbo 130 Griffin [Tech Pack] 5dr Auto

Minimum Kerbweight:

1421

Gross Vehicle Weight:

1900

Fuel Tank Capacity (Litres):

52

Max. Towing Weight - Braked:

1400

Max. Towing Weight - Unbraked:

680

Max. Loading Weight:

479

Luggage Capacity (Seats Up):

597

No. of Seats:

5

Max. Roof Load:

75

Luggage Capacity (Seats Down):

1634

Length:

4642

Width:

1860

Wheelbase:

2732

Width (including mirrors):

2062

Height:

1443

Height (including roof rails):

0

EC Directive 1999/100/EC Applies:

WLTP - MPG - Low:

37.7

WLTP - MPG - Medium:

47.1

WLTP - MPG - High:

55.4

WLTP - MPG - Extra High:

47.1

WLTP - MPG - Comb:

49.5

WLTP - MPG - Comb - TEL:

47.9

WLTP - MPG - Comb - TEH:

46.3

WLTP - FC (l/100km) - Low:

7.5

WLTP - FC (l/100km) - Medium:

6

WLTP - FC (l/100km) - High:

5.1

WLTP - FC (l/100km) - Extra High:

6

WLTP - FC (l/100km) - Comb:

5.7

WLTP - FC (l/100km) - Comb - TEL:

5.9

WLTP - FC (l/100km) - Comb - TEH:

6.1

0 to 62 mph (secs):

9.9

Top Speed:

130

Engine Power - BHP:

130

Engine Power - PS:

1

0 to 60 mph (secs):

Engine Power - KW:

96

Engine Power - RPM:

5500

Engine Torque - LBS.FT:

170

Engine Torque - NM:

230

Engine Torque - RPM:

1750

Engine Torque - MKG:

23.5

Cylinders - Bore (mm):

75

Cylinders - Stroke (mm):

90.5

CC:

1199

Cylinders:

3

Cylinder Layout:

IN-LINE

Number of Valves:

12

Camshaft:

DOHC

Fuel Delivery:

TURBO INJECTION

Catalytic Convertor:

1

Engine Layout:

FRONT TRANSVERSE

Compression Ratio:

10.5:1

Transmission:

SEMI-AUTO

Gears:

8 SPEED

Engine Code:

EB2ADTSME1

Coin Series:

Griffin [Tech Pack]

Coin Description:

Turbo 130

Standard manufacturers warranty - Years:

3

Standard manufacturers warranty - Mileage:

60000

Manufacturers Paintwork Guarantee - Years:

1

Man Corrosion Perforation Guarantee - Years:

6

Safety Concerns?:

Special Edition:

Special Order:

Based On ID:

0

Insurance Group 1 - 50 Effective January 07:

19E

Service Interval Mileage:

12500

Service Interval Frequency - Months:

12

Timing Belt Interval Mileage:

62500

Timing Belt Interval Frequency - Months:

72

NCAP Adult Occupant Protection %:

80

NCAP Child Occupant Protection %:

82

NCAP Pedestrian Protection %:

67

NCAP Safety Assist %:

66

NCAP Overall Rating - Effective February 09:

4

Badge Power:

130

Badge Engine CC:

1.2

Vehicle Homologation Class:

M1

Generation Mark:

6

Alternative Fuel Qualifying:

Tyre Size Front:

225/45 R17

Tyre Size Rear:

225/45 R17

Tyre Size Spare:

TYRE REPAIR KIT

Wheel Type:

17" ALLOY

Wheel Style:

N

Alloys?:

1

Space Saver?:

Standard Emissions:

EURO 6

HC+NOx:

Particles:

WLTP - CO2 (g/km) - Low:

170

WLTP - CO2 (g/km) - Medium:

136

WLTP - CO2 (g/km) - High:

115

WLTP - CO2 (g/km) - Extra High:

134

WLTP - CO2 (g/km) - Comb:

133

WLTP - CO2 (g/km) - Comb - TEH:

133

WLTP - CO2 (g/km) - Comb - TEL:

133

Emissions Test Cycle:

WLTP

RDE Certification Level:

RDE 2

PAS:

Front and rear parking distance sensors:

Driver drowsiness alert system:

Speed sign recognition:

Extended traffic sign recognition:

In-crash braking:

Shift paddles:

Lane departure warning with lane keep assist:

Adaptive cruise control with intelligent speed adaption:

Drive Smart - Live navigation provided by TomTom and Real time traffic news:

180 degree rear view camera:

Drive mode selector (Eco, Normal, Sport):

Heated front seats:

Rear head restraints:

Front head restraints:

Front and rear seatbelts:

3 seat bench in 2nd row:

Rear centre headrest:

4 way adjustable front passenger seat:

Single front passenger seat:

40/20/40 split-folding rear seat backs:

8 way adjustable AGR ergonomic active drivers seat:

ISOFIX Child seat mountings on outer rear seats incorporating top tether mounting points (without child seat):

Illuminated vanity mirrors:

Driver's and front passenger's sunvisors:

Heated rear window:

Dark tinted rear windows:

Intermittent rear window wash/wipe:

Windscreen and side window demist vents:

Electrically operated front and rear windows with safety auto reverse and one touch up/down facility:

Two speed rain-sensitive windscreen wipers with variable intermittent wipe:

Soundproof insulated windscreen:

Electronic brake force distribution:

Cornering brake control:

Emergency brake assist:

Electronic parking brake:

Hill start assist:

Anti-lock braking system (ABS):

Automatic emergency braking with pedestrian detection:

Drag torque control:

Straight line stability control:

Fading brake support:

Forward collision alert at low speed:

Electronic stability programme (ESP) with traction control:

Locking wheel bolts:

Deadlocking system:

Key left in ignition audible warning:

Remote control central locking:

Keyless entry and start:

Remote control ultrasonic security alarm system:

Service interval indicator:

Lights on audible warning:

Vauxhall connect:

RDS with traffic programme:

Phone book access:

Digital central facia display with audio info, digital clock with automatic RDS time adjustment and Outside air temperature with ice warning function:

Driver information display - Total mileage, service due indicator, oil life:

Digital instrumentation - Speedometer,rev counter,satellite navigation display,low fuel & water temperature warning light,shift up/down indicate light:

Multifunction trip computer - Trip mileage, vehicle range, average speed and fuel economy, instantaneous fuel economy and driving time:

European coverage:

2D/3D street level mapping:

Points of interest search and Map updates via USB:

Customizable screen adaption with enhanced profile management and driver recognition:

Multimedia Pure Panel Pro navigation system - 10" colour touchscreen and 10" digital instrument cluster:

Rear reading lights:

Illuminated load area:

Fade up/down front and rear courtesy light:

Interior tailgate handle:

Front door pockets:

Rear door pockets:

Glovebox with lid:

Heated steering wheel:

Chrome effect interior door handles:

Front centre armrest with cupholder:

Storage compartment in centre console:

Reach and rake adjustable steering column:

12V electrical accessory socket in front:

Twin gas assisted tailgate struts:

Folding storage box on driver side lower facia:

Black headliner:

Four lashing eyes in load compartment:

Rubber pedals:

Easy accessible storage boxes in the boot floor accommodate tyre inflation kit and first aid kit:

Side storage with nets:

Luggage compartment retractable cover:

Spare wheel storage area:

Modene fabric upholstery with side bolsters and surrounds:

Flex load floor with 2 storage nets:

Intelli-Space load floor adjustable in two heights for flat load area, adds additional 40 litres of load volume in lower position:

Three spoke flat bottom design steering wheel:

Black door mirrors:

Manual folding door mirrors:

Twin electrically adjustable and heated door mirrors:

Frameless automatic anti dazzle rear-view mirror:

6 speakers:

DAB Digital radio:

Steering wheel audio, phone and cruise controls:

Bluetooth connectivity with A2DP audio streaming function (Advanced audio distribuition profile):

AM/FM stereo radio with 36 station presets:

Front USB connection with iPod control:

Pollen filter:

Four adjustable facia vents:

Electronic climate control:

Heating, ventilation and air Conditioning (HVAC) user interface:

Outer rear seatbelt pretensioners:

Tyre pressure monitoring system:

Child locks on rear doors:

Front and outer rear seatbelt force limiters:

3x3 point rear seat belts:

Rollover mitigation:

Deactivation switch for front passengers front and side impact airbags:

Seatbelt unfastened audible warning and warning light:

8 Airbags - Drivers and front passengers airbags, Front seat side-impact airbags and Full-size curtain airbags:

Upper and lower bumper design to reduce upper and lower leg injuries:

Tailgate:

Wireless charger for mobile devices:

eCall emergency system:

Breakdown call (b-call):

Vehicle status and information:

Over the air updates and WiFi updates:

Manual headlight levelling:

Door to door illumination:

Automatic lighting control:

Adaptive brake lights:

LED daytime running lights:

High beam assist:

LED third brake light:

LED side repeat indicators:

Intelli-LED headlights and tail lights:

Emergency tyre inflation kit:

High gloss black roof rails:

Body coloured door handles:

Shark fin aerial:

Black lower window frame moulding:

Rear side wing doors:

Active bonnet/headlight/wiper structure:

Carbon black roof and rear roof spoiler:

Body colour bumpers with grained black lower front grille and rear valance panel:

Chrome-effect Griffin logo and Black vizor frame:

17" Black diamond cut alloy wheels:

Fully carpeted load area:

Natural voice recognition:

Vehicle microphone:

SMS read out and reply:

Handsfree calls via steering wheel controls:

Wireless Apple CarPlay/Android Auto:

Instrument panel bar in Alexit grey:

Black facia with modene trim inserts:

Birdie grey trim inserts on front doors:

Independent decoupled MacPherson strut front suspension with gas pressure dampers and coil springs, anti-roll bar:

Compound crank rear suspension with coil springs and gas pressure dampers:
