Toyota Corolla Hatchback 2.0 Hybrid 178 Icon 5dr CVT

Minimum Kerbweight:

1385

Gross Vehicle Weight:

1910

Fuel Tank Capacity (Litres):

43

Max. Towing Weight - Braked:

750

Max. Towing Weight - Unbraked:

450

Max. Loading Weight:

525

Luggage Capacity (Seats Up):

313

No. of Seats:

5

Max. Roof Load:

75

Luggage Capacity (Seats Down):

1004

Turning Circle - Kerb to Kerb:

10.4

Length:

4370

Width:

1790

Wheelbase:

2640

Height:

1460

EC Directive 1999/100/EC Applies:

WLTP - MPG - Low:

76.4

WLTP - MPG - Medium:

83.1

WLTP - MPG - High:

68.9

WLTP - MPG - Extra High:

49.6

WLTP - MPG - Comb:

62.8

WLTP - MPG - Low - TEL:

76.4

WLTP - MPG - Low - TEH:

68.4

WLTP - MPG - Medium - TEL:

83.1

WLTP - MPG - Medium - TEH:

72.5

WLTP - MPG - High - TEL:

68.9

WLTP - MPG - High - TEH:

63.8

WLTP - MPG - Extra High - TEL:

49.6

WLTP - MPG - Extra High - TEH:

45.2

WLTP - MPG - Comb - TEL:

62.8

WLTP - MPG - Comb - TEH:

57.3

WLTP - FC (l/100km) - Low:

3.7

WLTP - FC (l/100km) - Medium:

3.4

WLTP - FC (l/100km) - High:

4.1

WLTP - FC (l/100km) - Extra High:

5.7

WLTP - FC (l/100km) - Comb:

4.5

WLTP - FC (l/100km) - Low - TEL:

3.7

WLTP - FC (l/100km) - Low - TEH:

4.1

WLTP - FC (l/100km) - Medium - TEL:

3.4

WLTP - FC (l/100km) - Medium - TEH:

3.9

WLTP - FC (l/100km) - High - TEL:

4.1

WLTP - FC (l/100km) - High - TEH:

4.4

WLTP - FC (l/100km) - Extra High - TEL:

5.7

WLTP - FC (l/100km) - Extra High - TEH:

6.3

WLTP - FC (l/100km) - Comb - TEL:

4.5

WLTP - FC (l/100km) - Comb - TEH:

4.9

0 to 62 mph (secs):

7.4

Top Speed:

112

Engine Power - BHP:

178

Engine Power - PS:

1

0 to 60 mph (secs):

Engine Power - KW:

131

Engine Power - RPM:

6000

Engine Torque - LBS.FT:

140

Engine Torque - NM:

190

Engine Torque - RPM:

4400

Engine Torque - MKG:

19.4

Cylinders - Bore (mm):

80.5

Cylinders - Stroke (mm):

97.6

CC:

1987

Cylinders:

4

Cylinder Layout:

IN-LINE

Number of Valves:

16

Camshaft:

DOHC

Fuel Delivery:

MULTI POINT FUEL INJECTION

Catalytic Convertor:

1

Engine Layout:

FRONT TRANSVERSE

Compression Ratio:

14.0:1

Transmission:

AUTO

Gears:

1 SPEED

Engine Code:

M20A-FXS

Coin Series:

Icon

Coin Description:

Hybrid 178

Standard manufacturers warranty - Years:

3

Standard manufacturers warranty - Mileage:

60000

Safety Concerns?:

Special Edition:

Special Order:

Based On ID:

0

Insurance Group 1 - 50 Effective January 07:

21E

Service Interval Mileage:

10000

Service Interval Frequency - Months:

12

NCAP Adult Occupant Protection %:

0

NCAP Child Occupant Protection %:

0

NCAP Pedestrian Protection %:

0

NCAP Safety Assist %:

0

NCAP Overall Rating - Effective February 09:

0

Badge Power:

178

Badge Engine CC:

2

Vehicle Homologation Class:

M1

Generation Mark:

11

Alternative Fuel Qualifying:

1

Tyre Size Front:

205/55 R16

Tyre Size Rear:

205/55 R16

Tyre Size Spare:

TYRE REPAIR KIT

Wheel Type:

16" ALLOY

Wheel Style:

5 DOUBLE SPOKE

Alloys?:

1

Space Saver?:

Standard Emissions:

EURO 6

Noise Level dB(A):

65

CO:

0.155

HC:

0.014

NOx:

0.005

HC+NOx:

0.015

Particles:

0.0001

WLTP - CO2 (g/km) - Low:

84

WLTP - CO2 (g/km) - Medium:

76

WLTP - CO2 (g/km) - High:

92

WLTP - CO2 (g/km) - Extra High:

130

WLTP - CO2 (g/km) - Comb:

101

WLTP - CO2 (g/km) - Low - TEL:

84

WLTP - CO2 (g/km) - Low - TEH:

93

WLTP - CO2 (g/km) - Medium - TEL:

76

WLTP - CO2 (g/km) - Medium - TEH:

88

WLTP - CO2 (g/km) - High - TEL:

92

WLTP - CO2 (g/km) - High - TEH:

100

WLTP - CO2 (g/km) - Extra High - TEL:

130

WLTP - CO2 (g/km) - Extra High - TEH:

141

WLTP - CO2 (g/km) - Comb - TEH:

111

WLTP - CO2 (g/km) - Comb - TEL:

101

Battery Capacity in kWh:

1.8

Battery Type:

Lithium-ion

Emissions Test Cycle:

WLTP

RDE Certification Level:

RDE 2

Heated front seats:

Passenger seat back pocket:

3 rear headrests - integrated in centre:

Front head restraints:

3 rear height adjustable headrests:

60/40 split folding rear seat:

3 seat bench in 2nd row:

Whiplash Injury Lessening (WIL) feature (active headrest) for seats:

Manual height adjustable for driver and front passenger seat:

Power adjustable lumbar support on driver seat:

Manually sliding driver seat:

Manually sliding front passenger seat:

ISOFIX child restraint system:

Electric lumbar support for passenger:

Front passenger seat:

Forward tilting 2nd row seats:

Rain sensor:

Power front windows:

Front wiper de-icer:

Power rear windows:

Rear window wiper:

Auto up and down function on all power windows:

Anti-jam protection on power windows:

Time adjustment on intermittent wiper:

Rear window defogger:

UV-filter on driver and passenger windows:

UV-filter on rear windows:

Noise reduction layer on windscreen:

Aerofins on rear window:

Remote central locking + deadlocks:

Locking wheel bolts:

Power door locks:

Power passenger window lock:

Acoustic vehicle alert system (AVAS):

Alarm with motion sensor and immobilizer:

Traction control:

Brake assist function:

HAC - Hill start assist control:

Electronic parking brake:

Downhill Assist Control (DAC):

Anti lock braking system + Electronic brake force distribution:

Emergency brake light signal (EBS):

Rear armrest:

Front and rear door pockets:

Parcel shelf:

Front console box:

Heated steering wheel:

Fabric upholstery:

12v power outlet - front:

Voice recognition switch on steering wheel:

Rear overhead assist grips:

Front overhead assist grips:

Rear passenger coat hooks (2):

Adaptive cruise control (ACC) switch on steering wheel:

Adjustable speed limiter switch on steering wheel:

Satin chrome inside door handles:

Paddle shifts:

Boot underfloor storage:

Sliding armrest on centre console box:

Front and rear cup and bottle holders:

Leather gear shift with satin chrome on gear shift console:

Power window switches with satin chrome inserts:

Slow opening glovebox with lights:

Manual tilt and telescopic steering wheel:

Front sliding fabric armrest:

Black armrest on centre console box:

Satin chrome surround on speedometer:

Satin chrome surround on heater control panel:

4 tie down hooks in luggage compartment:

2 Shopping bag hooks in luggage compartment:

USB charger front:

Aluminium door scuff plates with corolla badge:

Satin chrome inserts on centre air vents:

Gloss black gear shift console:

Satin chrome surround on multimedia:

Single compartment glovebox:

Audio, multi-info and telephone switches on steering wheel:

Satin chrome insert on steering wheel:

Synthetic leather gear shift knob:

3 spoke synthetic leather steering wheel:

USB-C Cable:

Black door mirrors:

Manual folding door mirrors:

Power adjustable heated door mirrors:

Turning signal integrated indicators in door mirrors:

Manual day/night rear view mirror:

6 speakers:

DAB Digital radio:

AM/FM radio:

USB and Aux in connectors + 12V front outlet:

USB connector:

Front USB-C in dashboard:

Smart voice assist/ Voice recognition:

Pollen filter:

Clean air filter:

Dual zone automatic air conditioning with ECO mode switch:

Remote air conditioning:

Vehicle Stability Control (VSC):

MacPherson front suspension:

Double wishbone rear suspension:

Body coloured bumpers:

Body colour rear roof spoiler:

Black door moulding:

Body coloured outside door handles:

Body coloured front spoiler:

Body coloured shark fin antenna:

Body coloured rear bumpers:

Unique lower skirt:

Unique side rocker with black insert:

Black toyota logo in front:

Black window frame:

Gloss black upper front grille:

Rear side wing doors:

New grille pattern:

Body coloured rear under guard:

Satin chrome insert on front air vents:

Piano black diffuser:

Satin chrome insert on front door assist grips:

Black surround on lower front grille:

B - Pillar in Black:

Black side air vents:

Black meshed lower front grille:

Boot light:

Illuminated entry system in room lamp:

Driver and front passenger personal light:

LED centre room light:

Tailgate:

Electrically assisted power steering:

Wireless charger:

Connected car functionality upgrade, tracker, remote status and e-care:

Smart entry and push button start:

Front floor mats:

Textile floor mats:

Seatbelt pretensioners and force limiters:

Child locks on rear doors:

3x3 point rear seatbelts:

Front seatbelt reminder:

Front passenger airbag on/off switch:

Rear seat belt reminder:

Tyre pressure warning system:

Supplemental restraint system (SRS) 7 airbags - dual driver, dual side curtain, side impact and driver knee airbags:

Adjustable driver and front passenger seat belt extender to top anchor point:

Rear seat reminder alert:

Safety kit:

Follow me home headlights:

LED daytime running lights:

LED front fog lights:

Auto headlights:

LED rear combi lights with LED lightguide:

LED High mounted stop light:

Manual headlight levelling system:

LED multi reflector headlights:

Adaptive automatic high beam system (AHS):

LED headlights low:

Tyre repair kit:

Bluetooth telephone connectivity:

E-call:

Satin chrome dashboard inserts:

Soft touch texture on upper dashboard:

Stitching on lower dashboard:

Adjustable speed limiter:

Lane departure alert - LDA:

Intelligent clearance sonar:

Lane Departure Alert (LDA) switch on steering wheel:

Memory on adjustable speed limiter:

Front and rear parking sensors with auto brake:

Driver monitoring camera:

Proactive driving assist (PDA):

Toyota remote services:

Drive mode select (Eco, Normal):

MyT connected services:

Rear view camera with guidelines:

Gasoline particulate filter:

Driver and passenger sun visor with mirror and light:

Key reminder warning:

EV drive indicator:

Washer fluid level warning:

Full Digital 12.3" TFT Digital Combimeter:

10.5" Multimedia display screen:

Toyota smart connect navigation:

Smartphone integration with Apple CarPlay and wired android auto:

Colour multi information display with 3D:

12.3" multi information screen:

Toyota smart connect multimedia system:

Unique wheel finish with red wheel cap:

Toyota safety sense 3 pack - Corolla:

16" 5 double spoke silver metallic alloy wheels:
